149
Appendix
 Correlation diagrams of speed and load capacity of the dust-proof/splash-proof type
(Note) In the above graphs, the figure after each model type indicates a lead.
(Note 1) The graphs under “Horizontal installation” assume use of an external guide(s).
(Note 2) If the actual payload corresponds to the maximum load capacity for the applicable speed, the
actuator may overshoot due to vibration. Select an appropriate payload by providing an allowance
of 70% or so.
High
-spee
d type
Medium
-spee
d type
Low-spee
d type
Horizontal installation
(Note 1)
Vertical installation
(Note 2)
Loa
d cap
a
city (kg)
Loa
d cap
a
city (kg)
Loa
d cap
a
city (kg)
Speed (mm/sec) Speed (mm/sec)
Speed (mm/sec) Speed (mm/sec)
Speed (mm/sec) Speed (mm/sec)
Loa
d cap
a
city (kg)
Loa
d cap
a
city (kg)
Loa
d cap
a
city (kg)
