USER’S MANUAL
Section 4: BASIC OPERATION & INSTALLATION 69
AUTO
2 DIGITS
DROP
Four Times
DIAL
Ready
Ready
Connected
Connected
h
HOT TIP!
You can use dial setups as a way to conveniently change your codec settings. Possibly to
accommodate incoming calls from differing locations.
Simple leave the Number 1 & Number 2 field blank, and set Include to Codec. As always, be
sure to set the CODEC menu items to the proper settings before creating your setup.
Activating a Dial Setup – Step by Step
Before beginning, verify the Zephyr Xstream is
connected and ready for use. In most cases the
line status should indicate Ready & Ready (with
ETS 300 ISDN it is acceptable if Deactivated &
Deactivated is displayed)
If necessary, activate the appropriate Location
Setup for the location (if you have just arrived
there) now (see below). Or you may need to
manually configure SPIDs, DNs/MSNs and Telco
information in the Tel menu (if no Location
Setup exists for this location).
1. Press the
Dial Setup will be highlighted (white text on a
black background. To activate this Setup Press
2. To choose a different Dial Setup you have two
options:
• Use the <
5> and <6> to scroll through the
list of 100 Dial Setups.
• Or: Use the Keypad to enter the two‐digit
number (00 to 99) for the desired setup.
That setup will be displayed and will be
highlighted.
3. Once the desired setup is highlighted, press the
