USER’S MANUAL
Section 10: APPLICATIONS GUIDE 183
CCS Roadrunner at far end
Far End Setting
(ID #):
Set Local
Receive Mode
to:
Set Local
Transmit
Mode to:
Set Local
Sample Rate
to:
Set Local
Bit Rate to:
1: L2/56/24YES:QS L2 64 L2 Half 64 + Any 56 kbps
3: L2/56/32YES:QS L2 64 L2 Mono 64 32 kHz 56 kbps
5: L2/56/48YES:QS L2 64 L2 Mono 64 48 kHz 56 kbps
7: L2/64/24YES:QS L2 64 L2 Half 64 + Any 64 kbps
9: L2/64/32YES:QS L2 64 L2 Mono 64 32 kHz 64 kbps
11: L2/64/48YES:QS L2 64 L2 Mono 64 48 kHz 64 kbps
13: L2112/32YES:QS L2 L2 Mono 128 32 kHz 56 kbps (2)
15:L2112/48YES:QS L2 L2 Mono 128 48 kHz 56 kbps (2)
17:L2128/32YES:QS L2 L2 Mono 128 32 kHz 64 kbps (2)
19:L2128/48YES:QS L2 L2 Mono 128 48 kHz 64 kbps (2)
23:L3/56/32YES:QS L3 Dual/Mono L3 Dual/Mono 32 kHz 56 kbps
25:L3/56/48YES:QS L3 Dual/Mono L3 Dual/Mono 48 kHz 56 kbps
29:L3/64/32YES:QS L3 Dual/Mono L3 Dual/Mono 32 kHz 64 kbps
31:L3/64/48YES:QS L3 Dual/Mono L3 Dual/Mono 48 kHz 64 kbps
33:L3112/32YES:QS L3 L3 Mono 128 32 kHz 56 kbps (2)
35:L3112/48YES:QS L3 L3 Mono 128 48 kHz 56 kbps (2)
37:L3128/32YES:QS L3 L3 Mono 128 32 kHz 64 kbps (2)
39:L3128/48YES:QS L3 L3 Mono 128 48 kHz 64 kbps (2)
40:G722/56NO:QS G.722 G.722 * Any 56 kbps
41:G.722/56YES:QS G.722 G.722 * Any 56 kbps
42:G.722/64NO:QS G.722 G.722 * Any 64 kbps (1)
43:G.722/64YES:QS G.722 G.722 * Any 64 kbps (1)
(1) = Dial up one B channel only, or this mode may not work
(2) = Both B channels must be dialed for this mode
* Actual Sample Rate will be 16 kHz regardless of setting
+ Actual Sample Rate will be 24 kHz regardless of setting
