USER’S MANUAL
Section 12: System Functions and Remote Control 246
TRANSMIT MODE RATE (bps)
L3 Dual/Mono
2400
L3 Stereo/Jstereo 9600
L3 Mono 128
9600
AAC Mono 64
AAC-LD Mono 64
2400
AAC Stereo/Jstereo
AAC-LD Stereo/Jstereo
9600
AAC Mono 128
AAC-LD Mono 128
9600
L2 Mono 64 2400
L2 Half 64
2400
Ancillary data is supported in these modes when the Interface option in
the third TEL menu is set to ISDN, Ethernet, or V.35 split.
When set to V.35 Single, Ancillary data operates at 9600bps.
w
IMPORTANT!
When the Interface option in the third TEL menu is set to V.35 Single ancillary data is
possible in all permissible transmit modes at 9600 bps.
How to Control Ancillary Data Transmission
Ancillary Data Commands
• atdt Immediately switches to transparent mode and disconnects any Telnet clients.
• To switch off transparent mode and to gain access to control commands
again, enter +++. (Do not transmit any data within a guard time of 1 second
before giving this command.)
• +++ Switches off transparent mode and automatic transparent mode
activation and return to Zephyr command interpreter.
• atdt nobreak Immediately switches to transparent mode and disconnects any Telnet clients.
Unit will remain in transparent mode until a restore factory defaults is performed.
