USER’S MANUAL
Section 3: GUIDED TOUR of the HARDWARE 42
Fast Access Menu Keys – AUDIO, CODEC, TEL, SYSTEM
These keys are used to instantly jump to a desired
menu. The first key‐press displays a summary
status screen for that menu. Subsequent presses
page through the pages of options for that menu.
The idea is to make it easy to jump directly to a
desired menu, simply by pressing the desired
menu key a specific number of times.
See Section 5 (Guided Tour of the Menus) and
Section 11 (Detailed Menu Reference) for more
information.
h
HOT TIP!
Note that the CODEC, TEL, & SYSTEM menus (and Navigation and Menu Selection Keys)
are identical among all models of the Zephyr Xstream. Only the AUDIO menu varies between
the Xstream (non-mixer) and Xstream MX/MXP (mixer) versions.
Navigation and Menu Selection Keys
These keys are used to move through the menu options on a given page of menu
items. Once the desired menu item has been highlighted, (displayed with white text
on a black background) pressing the <SEL> selects this option. You can then use the
<
5
>
or
<
6
>
keys to view the options for this item (or to change the position of a
sliding control). The previous setting will have [ ] around it. Pressing the <SEL> key
once again saves your selection.
Pressing any Menu key will abort the entry process and allows you to “escape”.
Numeric Keypad
The operation of this is straightforward. A given button corresponds to the
number printed on it. It can also be used for text entry of the letters associated
with it. Additional characters are available on the <*> key (i.e. * ( [ ] < >
and the <#> key (i.e. # . , ; : ! ?
key.
To enter text characters, press the key with the appropriate letter printed near it.
Keep tapping it to cycle through the possible choices. For example, tapping the 2‐
key in a text field will first enter A. Repeated taps will change that to a B, then C,
