USER’S MANUAL
Section 10: APPLICATIONS GUIDE 182
CCS CDQ Prima at far end
Far End Setting
(ID #):
Set Local
Receive Mode
to:
Set Local
Transmit
Mode to:
Set Local
Sample Rate
to:
Set Local
Bit Rate to:
6: G.722_56K:QS G.722 G.722 * Any 56 kbps
7: G.722_64K:QS G.722 G.722 * Any 64 kbps
24:ZEPHYR/56K:QS L2 64 L2 Mono 64 48 kHz 56 kbps
25:ZEPHYR/64K:QS L2 64 L2 Mono 64 48 kHz 64 kbps
26:ZEPHY/112K:QS L2 L2 Mono 128 48 kHz 56 kbps (2)
27:ZEPHY/128K:QS L2 L2 Mono 128 48 kHz 64 kbps (2)
30:LYR3IND56:QS L3 Dual/Mono L3 Dual/Mono 48 kHz 56 kbps
31:LYR3IND64:QS L3 Dual/Mono L3 Dual/Mono 48 kHz 64 kbps
32:LYR3IND56/32:QS L3 Dual/Mono L3 Dual/Mono 32 kHz 56 kbps
33:LYR3IND64/32:QS L3 Dual/Mono L3 Dual/Mono 32 kHz 64 kbps
36:ZEPHY112MONO:QS L2 L2 Mono 128
or L2 J-Stereo
or L2 Stereo
48 kHz 56 kbps (2)
37:ZEPHY128MONO:QS L2 L2 Mono 128
or L2 J-Stereo
or L2 Stereo
48 kHz 64 kbps (2)
(2) = Both B channels must be dialed for this mode
* Actual Sample Rate will be 16 kHz regardless of setting
Note: Rev 6.32 Primas support all of the above pre-sets (unless they have been overwritten by the user). Earlier models may
not include all of the above.
