USER’S MANUAL
Section 11: THE WORKS – Detailed Menu Reference 200
Mon “x” Rcv Mix
This parameter, in combination with Mon "x" Rcv Pan selection is useful for when only a single
return channel is being sent from the far end. The default is stereo. The options are:
Stereo:
This choice routes the incoming (far end) audio to the headphones as received.
The A channel audio appears on the Left side of the Local Mix and the B channel
audio appears in the Right side of the Local Mix.
A:
This option routes the incoming A channel audio to both sides of the Local Mix.
B:
This option routes the incoming B channel audio to both sides of the Local Mix.
Note that the "A" or "B" options allow a single incoming signal to be output on
both channels of the Local Mix.
Mono A + B:
This option sums (i.e. mixes) the incoming A & B audio channels and routes this
to both sides of the Local Mix.
This can be particularly useful when the both a mix minus and a producer IFB
(interruptible foldback) are being received, as it allows both feeds to be heard in
both ears.
Mon “x” Rcv Pan
This control determines the ratio of the amount of the audio fed to the A (Left) and B (Right)
channels of the Local Mix.
Mon “x” Xmt Mix
This option operates in the same was as Mon "x" Rcv mix, only the send audio is used. This is
particularly useful when creating two separate mono mixes to be sent to two far end locations,
as it can allow the talent to hear the correct return mix in both ears. The options are:
Stereo:
This choice routes the outgoing (near end) audio to the headphones just as
transmitted by the codec section. The A channel audio appears on the Left side
of the Local Mix and the B channel audio appears in the Right side of the Local
Mix.
A:
This option routes the outgoing A channel audio to both sides of the Local Mix.
