USER’S MANUAL
Section 11: THE WORKS – Detailed Menu Reference 198
MIC +30: ‐40 dBu (nom)
Line Con: ‐10 dBu (nom)
Line Pro: +4 dBu (nom)
The nominal values given above assume the fader is mid‐position and the AGC/Limiter
(processor) is off
Ch “x” Pan
This menu selection is a "panorama" adjustment that allows you to vary the amount of audio
sent to the A and B codec inputs. Note that this adjustment has no effect unless the input "x"
has been assigned to both A and B using the front panel control.
Ch “x” Proc
This menu selection allows you to enable the built in AGC/Limiter (processor) for Main Mixer
input "x". You will be able to see the level for input "x" as well as the AGC and Limiter working
by looking at the small bar‐graphs and gate indicator to the right side of this screen. The built in
Omnia processor is quite sophisticated and offers the following options:
None:
This disables the input processor for channel "x".
Voice L:
(Voice Low) This is the least aggressive setting, intended to protect against
minor level problems when running a live show. This provides AGC with no
limiting. Ideal where you want the most natural sound in live situations where
mixing could be difficult.
Voice M:
(Voice Medium) This is a moderate setting. It combines AGC with a small
amount of limiting. This provides good dynamics control, and serves to "beef
up" the voice. This setting is the most frequently used general purpose setting
for voice.
Voice H:
(Voice High) This is an aggressive setting employing both AGC and limiting. This
setting is perfect for easily excited talent such as sportscasters.
