USER’S MANUAL
Section 14: SPECIFICATIONS and WARRANTY 295
• Bi‐directional ancillary data: Serial connection at 2400 or 9600 (AAC and Layer 3) bps;
eight contact closures (for end to end transmission or local status and control).
IP Support
• via Ethernet 100 Base‐T Ethernet port.
• Uses fixed IP address
• Port 23 supports Telnet sessions
• Port 80 used for HTML browser interface
• Port 8080 supports MPEG streaming in MPEG Layer 3 or AAC
• Port 5060 for SIP signaling
• Port 21 used for FTP software updates (10 Base‐T units only).
Software Upgrades
• Downloadable from Telos; browser based upload via 100Base‐T Ethernet connection.
Control Ports
• Eight bi‐directional inputs/outputs for end‐to‐end contact closure emulation.
• Inputs: Open collector, closure to ground. Integral pull up. Supports up to 24 volts DC
inputs
• Outputs: Sink up to 125 mA to ground. Integral pull up to 5 volts (voltages greater than
5 volts may be used with external pull‐ups)
Resolution
• Send Input: MPEG 24 bits; G.722 16 bits
• Receive Output: MPEG 24 bits; G.722 16 bits
Power Supply
• 90‐240 VAC (50/60 Hz) auto‐configuring.
• 100 watts peak
Dimensions, Zephyr Xstream and Zephyr Xstream MX
• 19" (48cm) standard rack mount front panel
• 17 1/8" (43cm) wide behind front panel
• 12 1/2" (32cm) deep
• 3 1/2" (9cm) high
Dimensions, Zephyr Xstream MXP
• 18 1/4" (46cm) wide
• 14" (36cm) deep
• 4 1/4" (11cm) high
Shipping weight
• 13 pounds (5.9 kg) (MXP)
• 9 pounds (4 kg) (non‐mixer)
CE approved
All specifications subject to change without notice
