USER’S MANUAL
Section 4: BASIC OPERATION & INSTALLATION 67
w
IMPORTANT TIP!
The Number field in the DIAL menu is different from other entry fields in the Zephyr
Xstream. It is NOT necessary to press <SEL> before entering the number to be dialed.
While we like consistency, this field is used so often, it made sense to make it easier by doing
this. It also makes operation more similar to the Zephyr classic.
If you wish to specify the Line to be used, or use a mode other than the default (i.e. other than
Zephyr,) you can do so. After entering the number, press <SEL>, then use the <
5> or <6> keys
to move to the desired menu selection, and press <SEL> again to change the item. Repeat this
process till all items are set as desired..
Once you have set the Line and Mode press <DIAL> to make the connection.
The available modes are:
• Zephyr ‐ Places a "data" mode call at the rate indicated in the CODEC menu.
• Phone ‐ Places a "voice" mode call according to the G.711 standard. This
allows placing a call to any standard telephone line.
• Xport ‐ Places a "voice" mode call according to the G.711 standard and loads
Xstream's modem code into DSP to allow communication with a Zephyr
Xport connected to a POTS (analog) line.
The DROP menu
The Drop menu is activated by pressing the <DROP> button once. It looks like this:
The system will default to Line 1 if that line is in use. It will default to Line 2 only if Line 1 is not in
use. Press <DROP> a second time to drop the line shown.
To drop a Line other than the line shown, press the <SEL> button, then press < 5> or <6> to
select the desired Line(s). To drop the Line(s) press <DROP> again.
To easily clear both ISDN lines simply press <DROP> four times.
For connecting when in Ethernet/IP mode, see Appendix 6,
The AUTO menu
The AUTO menu is used to enter or activate Dial Setups and Location Setups.
