Chapter 3 - Front Panel Operating Instructions HCD-E1 Installation & Operation Manual
3-24 Local Configuration Setup Procedure 11/01/00 19:52
To configure the unit, follow the steps below:
Step Action Key Result
1 Bring the cursor to the top row (if not already there). CURSOR
2 Scroll to display the desired group of parameters in the top
row. SCROLL The second row shows
the first parameter in the
selected group and its
current value.
Note: When the desired group of parameters must be separately selected for each data channel, the
top row includes an additional field (at the rightmost side of the top row): this field is used to select
the desired channel number.
3 Bring the cursor to the left-hand field (parameter name) in
the second row, and then scroll to display the desired
parameter in the selected group. CURSOR
SCROLL
4 Bring the cursor to the right-hand field (the parameter
value) in the second row. CURSOR
5 Scroll to set the required value for the displayed parameter. SCROLL The second row shows
the available values.
6 When the desired parameter value is displayed, confirm the
new parameter value.
Note: For the CHANNEL PRM, SL PARAMETERS and
DNLOAD PRM groups, you must press ENTER only after
you have changed all the parameters (that required
changes), otherwise HCD-E1 displays the CONFIG ERROR
message. For more information, see
Table 3-3 and
Table 3-5.
ENTER The second row displays
shortly CONFIG ENTER,
then returns to the
normal display.
7 Repeat steps 3 to 6 until values are assigned to all the
parameters in the group. SCROLL The second row displays
the current selection.
Note: You do not have to press ENTER each time you change a parameter within a group. However,
once you have finished to modify parameters of a certain group (such as system, sublink, etc.), you
must press ENTER to confirm the selection. If you change parameter values, but return the cursor to
the top row and scroll to another group without pressing ENTER, the changes are discarded and
HCD-E1 shortly displays the message CONFIG LOSS.
8 Repeat steps 1 to 7 until values are assigned to all the
parameters in the desired groups. CURSOR
SCROLL
ENTER
9 After completing the configuration actions, you can use
steps 1, 2 to return to the ALARM BUFFER screen.
If ON-state alarm messages are stored in the alarm buffer
and the current screen is not PORT DIAG or HDSL DIAG,
the ALARM BUFFER screen will be automatically displayed
if no push button is pressed for one minute. CURSOR
SCROLL The top row displays:
ALARM BUFFER.
Note Pressing ENTER accepts your choice only if the cursor is in the right-hand field
of the second row.
