Chapter 4 - Control from the Supervisory Port HCD-E1 Installation & Operation Manual
4-24 HCD-E1 Command Set Description 11/01/00 19:23
DEF PB Purpose
Define each time slot priority (high or low). In case one of the HDSL lines is
down, time slots with high priority will still continue to be sent on the
remaining line.
Syntax
DEF PB
Use
1. Type:
DEF PB
2. HCD-E1 displays the first line of the time slot map of the priority
bumping. A typical display is shown below:
TS_1 TS_2 ... ... TS_31
LOW HIGH ... ... LOW
3. If you want to change the priorities, use the spacebar to move between
time slots. For each desired time slot, select between HIGH and LOW
by pressing F or B.
4. After completing the first line, press to move to the next line.
Repeat the procedure until all the desired time slots are defined. When
done, press to finish. HCD-E1 displays the date and time
followed by the HCD-E1 prompt.
Note 1. The priority bumping will work in the framed mode only.
2. TS-0 has always HIGH priority. The maximum number of other time slots
that can be configured to high priority is 16.
DEF PWD Purpose
Define a new user password for the HCD-E1 system. The password must
have 4 to 8 characters.
Syntax
DEF PWD
Use
1. Type:
DEF PWD
The following password entry screen appears:
NEW PASSWORD (4 to 8 CHARS) =
