HCD-E1 Installation & Operation Manual Appendix E - IR-IP Interface Module
Diagnostic Tool (PING Terminal) Menu E-27
Using the Ping
Function The Ping option is used to confirm IP connectivity by pinging other IP
hosts. Connectivity is confirmed by receiving a reply from the remote
(pinged) IP host.
To ping a host:
1. From the Diagnostic Tools menu, type 1 and enter the desired host IP
address.
2. Press to confirm the destination IP address.
3. To start pinging, type 2 on the Diagnostic Tools screen.
After pinging starts, you can monitor the ping status. A typical screen
is shown in Figure E-26.
Note
After pinging is started, it continues in the background even if you exit the
Diagnostics Tools screen. In this case, a Ping Running message appears in the
top upper left-hand corner of the screen.
4. To stop pinging, type 3 from the Diagnostic Tools menu.
A Ping Stopped message is displayed.
To clear the message and return to the Diagnostic Tools screen,
press any key.
IR_IP S/W Ver. 1.00 31/IR (date)
Quick Setup
Management Access
Advanced Setup
Device Control
View
Diagnostic Tools (PING terminal)
=====================================================================
1. Ping IP Address :192.168.100.011
2. Start Pinging :>>>
3. Stop Pinging :>>>
Pinging 192.168.212.001 Sent 27 Recvd 25 Lost 2 Resp.Time 60 ms
Press one of the numbers to select or ESC:
Figure E-26 Diagnostic Tools Menu after Receiving Pinging Response
