HCD-E1 Installation & Operation Manual
Chapter 4 - Control from the Supervisory Port
11/01/00 19:23
HCD-E1 Command Set Description
4-23
DEF NAME
Purpose
Define the logical name (up to eight alphanumeric characters).
Syntax
DEF NAME
Use
1. To define the HCD-E1 logical name, type:
DEF NAME
HCD-E1 displays the logical name entry form:
ENTER NODE NAME (MAX 8 CHARACTERS) =
2. Type the desired name, and then press
following line:
CURRENT NAME = 'name'
(where 'name' is the logical name HCD-E1 is currently assigned), and
then the date and time, followed by the HCD-E1 prompt.
Note
If you want to store a logical name in the database, make sure that the DB
INIT section of the HCD-E1 internal switch S1 is set to OFF. Otherwise, the
default name (blank) is enforced.
DEF NODE
Purpose
Define the node number, or address, of HCD-E1. The allowed range is
0 to 255.
Syntax
DEF NODE
Use
1. Type:
DEF NODE
HCD-E1 displays the node entry form:
NODE (0 to 255) = 0
2. Type the desired number in the range of 0 to 255, and then press
followed by the HCD-E1 prompt.
Note
If you want to store the user-selected node number, make sure that the
DB INIT section of the HCD-E1 internal switch S1 is set to OFF. To use the
user-selected node number, set the PASSWD section of S1 to OFF.
Otherwise, the default number (0) is enforced.
