HCD-E1 Installation & Operation Manual
Quick Start Guide
11/07/00 13:21
Configuring HCD-E1
5
12. You can assign each HCD-E1 unit a logical name of up to eight
characters. The logical name helps identify the source of alarm
messages that HCD-E1 sends to the supervision terminal. Use the DEF
NAME
command to assign a logical name.
13. To reset HCD-E1, use the RESET command.
14. To reset a configuration of HCD-E1 to default values, use the INIT DB
command.
Note
•
The RESET and the INIT DB commands cause HCD-E1 to reinitialize,
disrupting traffic through HCD-E1 until it resumes normal operation.
•
Change of the framing mode causes double temporary synchronization
loss.
Tips
•
Use the HELP command to display the correct syntax of commands.
•
It is usually sufficient to configure the central unit only, in which case the
central unit’s configuration parameters are automatically downloaded to
the remote unit.
