Appendix E - IR-IP Interface Module HCD-E1 Installation & Operation Manual
E-24 View Menu
To access the Configuration and Connection screen:
•
From the View menu, type 1.
The View Configuration screen appears (Figure E-20).
IR_IP S/W Ver. 1.00 31/IR (date)
VIEW CONFIGURATION
------------------
BOOT Version :1.06 18.03.1999
Device Name :IP router card
System Location :The location of this device
Contact Person :Name of contact person
MAC Address : 00-20-D2-16-3F-9B
Default Gateway : WAN
Intrf Type Baud(Kbps) Prot IP Address IP Mask Status
.....................................................................
LAN UTP ------- Ethr 192.168.205.005 255.255.255.000 Connected
WAN V.110 FR Not Conn.
Press any key to continue:
Figure E-20 View Configuratiopn Screen
ARP Tables This screen is used to display the IR-IP ARP table. This table shows the IP
address assigned to each station on the LAN (the stations are identified by
their MAC addresses).
To access the ARP Tables screen:
•
From the View menu, type 2.
The ARP Tables screen appears (Figure E-21).
IR_IP S/W Ver. 1.00 31/IR (date)
ARP Table
---------
IP Address MAC Address IP Address MAC Address
192.168.205.003 00-40-33-20-C8-3C
Press any key for exit
Figure E-21 ARP Table Screen
