HCD-E1 Installation & Operation Manual Chapter 5 - Troubleshooting and Diagnostics
01/01/01 08:15 Configuration Error Messages 5-31
Step Action Key Result
16 To deactivate the BERT test, scroll to OFF
and press ENTER. ENTER
17 Deactivate the loopback on the appropriate
channel as described in the previous section.
Operating
Loopbacks from a
Control Terminal The diagnostic loopbacks can be operated by means of a control terminal,
using the LOOP and CLR LOOP commands. For more detail, see
description of the corresponding command in Section 4.5, HCD-E1
Command Set Description.
5.5 Configuration Error Messages
If HCD-E1 detects a configuration mismatch, it displays an appropriate
configuration error message. These messages appear both on the LCD and
on the supervision terminal. Some of the messages are not available on the
LCD. There is also one unavailable on the supervision terminal.
On the control terminal, configuration error messages have the format
ERROR, followed by a two-digit code and a short description of the error
message after the error code. The LCD displays CONFIG ERROR followed
by the error two-digit code, without description. Table 5-5 lists the
configuration error messages in order of their codes and explains each of
them. Messages not available on the LCD are marked with an asterisk (*).
Table 5-5 Configuration Error Messages
Error Code Terminal Message and Description
ERROR 01 ILLEGAL LOOP COMBINATION
You are trying to activate illegal combination of loopbacks.
ERROR 02* LOOP IS NOT ACTIVE
You are trying to disconnect a loopback that is not active.
ERROR 03 ILLEGAL COMMAND FOR CURRENT PORT MODE
You are trying to perform a command, which is illegal for the current configuration. For
example, you are trying to display the E1 sublink performance diagnostics while the
CRC-4 function is disabled, or you are attempting to configure remote HCD-E1, when
it is under control of central unit (CONFIG_REM parameter of the central unit is set to
YES) and the HDSL line is synchronized.
ERROR 04 On LCD only:
You are trying to change a parameter from the front panel when the password
protection is enabled
