Chapter 4 - Control from the Supervisory Port

HCD-E1

Installation & Operation Manual

4-38

HCD-E1 Command Set Description

11/01/00 19:23

Note

In case the CRC-4 function is disabled, HCD-E1 displays an error message:

ILLEGAL COMMAND FOR CURRENT MODE. If the CRC-4 function is enabled

on the sublink of the local unit, but disabled at the remote end, HCD-E1 will

display meaningless information.

DSP REM AGENT

Purpose

Display information on the SNMP agents that are known to the IP router of
the HCD-E1 when SNMP management is enabled.

Note

For SNMP management to be enabled, the following conditions must be

satisfied:
1. The units must have different IP addresses and different MUX_NAME’s.
2. A dedicated slot must be assigned in both units.

Syntax
DSP REM AGENT

Use

To display the remote agent information, type:

DSP REM AGENT

If not all conditions listed above are fulfilled, HCD-E1 displays the following
message:

CAN NOT FIND REMOTE AGENT

Otherwise, HCD-E1 displays a table listing the remote agents. A typical
display is shown below:

IP ADDRESS MUX NAME DISTANCE
--------------------------------------

192.114.50.2 RAD1 006
192.114.50.3 RAD2 012

The fields displayed for each agent are as follows:

IP ADDRESS

The IP address of the remote agent (see the DEF
AGENT
command above).

MUX NAME

The logical name of the remote agent (see the DEF
NAME
command above).

DISTANCE

The distance is a metric that indicates the logical
distance (through the management network) to the
remote agent, and is used, among other factors, in the
selection of the optimal route to be used by the
management traffic.
