HCD-E1 Installation & Operation Manual
Chapter 4 - Control from the Supervisory Port
11/01/00 19:23
HCD-E1 Command Set Description
4-25
2. Type the required password. Carefully check that the specified
password has been indeed typed in, and then press
displays the next line:
CURRENT PASSWORD = 'password'
where 'password' is the current password, and then the date and time,
followed by the HCD-E1 prompt.
Note
If you want to store the user-selected password, make sure that the DB INIT
section of the HCD-E1 internal switch S1 is set to OFF. To use the
user-selected password, set the PASSWD section of S1 to OFF. Otherwise, the
default password (HCD) is enforced.
DEF SL
Purpose
Select the sublink parameters of the HCD-E1
Syntax
DEF SL
Use
1. To define the sublink parameters, type:
DEF SL
HCD-E1 displays the first line of the sublink parameters data form. For
explanation of parameters and configuration guidelines, refer to
Table 3-3 in Chapter 3. A typical display is shown below:
FRAME
CRC-4
SYNC
MAP_TYPE
START_TS
NUM_OF_TS
IDLE_TS_CODE
G732N
NO
CCITT
USER
N/A
NC
FF
Note
If the FRAME field shows N/A, it means that one of the channels is in
UNFRAMED mode and all the 32 HDSL timeslots are assigned to it.
2. Change the parameter values using the spacebar to move between the
fields and pressing F or B to scroll among the available selections.
3. After the desired parameter values are selected, press
displays the second line of the data form:
TS_0
TS_1
TS_2
...
TS_9
NC
NC
DATA
...
NC
4. Use the spacebar to move between time slots. For each time slot, select
between DATA (time slot allocated to the current channel) and NC (not
connected) by pressing F or B.
5. After completing the first line of time slots, press
next line. Repeat the procedure until all the time slots are defined.
