HCD-E1 Installation & Operation Manual Appendix E - IR-IP Interface Module
View Menu E-25
Multicast Groups
Table Screen This screen is used to display information about the multicast group IP
addresses and their status.
To access the Multicast Groups Table screen:
•
In the View menu, type 3.
The Multicast Groups Table screen appears (Figure E-22).
IR_IP S/W Ver.1.00 31/IR (date)
Multicast Groups Table
----------------------
Group IP Address Status Group IP Address Status
Press any key for exit
Figure E-22 Multicast Groups Table Screen
Statistics Screen The Statistics screen is used to display statistical information on the traffic
between the networks connected by IR-IP. The data displayed on this
screen enables you to evaluate the IR-IP performance. Two different
Statistics screens are used, one for the LAN side and the other for the WAN
side.
To access the Statistics menu:
•
In the View menu, type 4.
The LAN and WAN Statistics screens appear (Figure E-23 and
Figure E-24).
IR_IP S/W Ver.1.00 31/IR (date)
SYSTEM STATISTICS
-----------------
Counter Name Val Counter Name Val
LAN in Octets 83504 LAN IP Header Errors 0
LAN Unicast Frames In 1 LAN IP Address Errors 0
LAN Non-Unicast Frames In 9 LAN Alignment Errors 0
LAN Out Octets 83504 LAN CRC Errors 0
LAN Unicast Frames Out 3560 LAN Single Collisions 0
LAN Non-Unicast Frames Out 0 LAN Multiple Collisions 0
LAN to WAN Frames Passed 1698 LAN Late Collisions 0
LAN IP Datagram Received 2638 LAN Excessive Collisions 0
LAN to CPU Frames Discarded 0 LAN Frames Too Long Errors 0
LAN to WAN Frames Discarded 0 LAN RX FIFO Overrun Error 0
LAN Out Errors 0 LAN SQE Transmitted 0
LAN RX Frames Errors 0 LAN Deferred Frames 1
LAN MAC Receive Errors 0 LAN Carrier Sense Lost 0
LAN MAC TX Errors 0 LAN FIFO Underrun 0
N - Next Screen. ESC - Back To Previous Menu.
R - Refresh Page. C - Clear The Counters Of This Page.
Figure E-23 LAN Statistics Screen
