HCD-E1 Installation & Operation Manual Chapter 4 - Control from the Supervisory Port
11/01/00 19:23 HCD-E1 Command Set Description 4-27
PWD Password protection:
YES
Password protection is enabled.
NO Password protection is disabled.
LOG_OFF Idle disconnect time:
NO
Automatic session disconnection disabled.
10_MIN Automatic disconnection after ten minutes if HCD-E1 receives no input.
CTS Determines CTS state:
ON
The CTS line is always ON (active).
=RTS The CTS line follows the RTS line.
DCD_DEL With the HCD-E1 control port defined as DTE, indicates the delay (in msec) between DCD=ON
and the sending of data.
Values: 0, 10, 50, 100, 200, 300 msec.
POP_ALM Controls the automatic display of alarms on the terminal:
YES
The terminal automatically displays the alarm status whenever an ON-type alarm
appears or an ON/OFF-type alarm changes its state to ON (for the term definition, see
Section 5.2 in Chapter 5). If no such event occurs, HCD-E1 displays the alarm status
every 10 minutes.
NO The automatic display feature is disabled.
DSR Determines the DSR state:
ON
The DSR line is continuously ON. It will switch to OFF for five seconds after the DTR line
is switched OFF.
DTR The DSR line tracks the DTR line. When INTERFACE=DTE, the DSR line will switch to
ON for five seconds when the RI line is ON while the DTR line is OFF.
AUXILIARY
DEVICE Selects the management mode supported by the HCD-E1 control port:
TERMINAL
Management by means of a supervision terminal.
NMS-SLIP Management by means of Telnet host or an SNMP network management station.
NONE Not in use
Note In order for HCD-E1 to use the selected parameters, verify that Section 3 -
DEF SP and Section 2 - DB INIT of Switch S1 (see “Setting the Internal
Jumpers and Switches” in Chapter 2) is in the OFF state (factory setting).
Otherwise, HCD-E1 will use the default parameters.
