HCD-E1 Installation & Operation Manual Appendix E - IR-IP Interface Module
Advanced Setup Menu E-19
Multicast IP
Menu The Multicast IP menu is used to specify the IP multicast frame forwarding
parameters, and to access the static multicast groups’ table.
To access the Multicast IP menu:
•
From the Advanced Setup menu, press 4.
The Multicast IP menu appears (Figure E-14).
IR_IP S/W Ver. 1.00 31/IR (date)
Quick Setup
Management Access
Advanced Setup
.....................................................................
Device identification
Interface Parameters
Protocol Parameters
Multicast IP
=====================================================================
1. Multicast forwarding :[ Disable ]
2. Static groups :>>>
Press one of the numbers to select or ESC:
Figure E-14 Multicast IP Menu
Multicast Forwarding
Used to control the forwarding of IP multicast frames. The following
selections are available:
•
DISABLED – Disables multicast forwarding in both directions.
•
LAN to WAN – Enables forwarding of IP multicast frames addressed to
groups appearing in the Static Multicast Groups table, from the LAN to
the WAN.
•
WAN to LAN – Enables forwarding of IP multicast frames addressed to
groups appearing in the Static Multicast Groups table, from the WAN to
the LAN.
•
BIDIRECTIONAL – Enables forwarding of IP multicast frames addressed
to groups appearing in the Static Multicast Groups table, in both
directions.
•
WAN to LAN + IGMP – Enables forwarding of IP multicast frames
addressed to groups appearing in the Static Multicast Groups table, from the
WAN to the LAN. In addition, more groups can be added dynamically (the
additional can be viewed using the View menu – Figure E-19).
•
TRANSPARENT – All the IP multicast frames are forwarded, irrespective
of the Static Multicast Groups table.
