HCD-E1 Installation & Operation Manual Chapter 4 - Control from the Supervisory Port
11/01/00 19:23 HCD-E1 Command Set Description 4-37
•
To display current values of the performance monitoring registers of the
HDSL line 1, and then clear all these registers and restart the count
intervals, type:
DSP R HDSL PM LP1/CA
or
DSP R HDSL PM/CA
•
To display current values of the performance monitoring registers of the
HDSL line 2, and then clear all these registers and restart the count
intervals, type:
DSP R HDSL PM LP2/CA
The format of the display is similar to the format for the performance
monitoring registers of the local unit, described in the DSP HDSL PM
section above.
DSP R SL PM Purpose
Display the contents of the sublink performance monitoring registers of the
unit located at the remote end of the HDSL link. This option is available
only when the CRC-4 function is enabled on both sublinks: at the local and
the remote ends of the HDSL link (see DEF SL command).
For an explanation of the sublink performance monitoring registers, refer to
Section 5-3.
Syntax
DSP R SL PM [Option]
Use
•
To display the performance monitoring registers of the sublink of the
remote unit, type:
DSP R SL PM
•
To display current values of the performance monitoring registers of the
sublink of the remote unit, and then clear only the event register, type:
DSP R SL PM /C
•
To display current values of the performance monitoring registers of the
sublink of the remote unit, and then clear all these registers and restart
the count intervals, type:
DSP R SL PM /CA
HCD-E1 performs the command and displays the date and the time
followed by the HCD-E1 prompt.
The format of the display is similar to the format for the local unit
performance monitoring registers, described in the DSP SL PM section
below.
