HCD-E1 Installation & Operation Manual
Chapter 4 - Control from the Supervisory Port
11/01/00 19:23
HCD-E1 Command Set Description
4-35
INTERVAL 01 ES = 000 UAS = 000 SES = 000 BBE = 000
ESR = 00.00% SESR = 00.00% BBER = 00.00%
INTERVAL 02 ES = 000 UAS = 000 SES = 000 BBE = 000
ESR = 00.00% SESR = 00.00% BBER = 00.00%
INTERVAL 03 ES = 000 UAS = 000 SES = 000 BBE = 000
ESR = 00.00% SESR = 00.00% BBER = 00.00%
INTERVAL 04 ES = 000 UAS = 025 SES = 026 BBE = 001
ESR = 00.00% SESR = 02.88% BBER = 00.11%
24 HOUR ES = 0
24 HOUR UAS = 25
24 HOUR SES = 26
24 HOUR BBE = 1
24 INTERVAL = 04
DSP PB
Purpose
Display the priority bumping of time slots selected by the user.
Syntax
DSP PB
Use
To display the priority bumping of time slots, type:
DSP PB
A typical display is shown below:
TIME SLOT MAPPING OF PRIORITY BUMPING
=====================================
TS:
0
1
2
3
4
5
6
7
8
9
PRIORITY:
HIGH
LOW
LOW
LOW
LOW
LOW
LOW
LOW
LOW
LOW
TS:
10
11
12
13
14
15
16
17
18
19
PRIORITY:
LOW
LOW
LOW
LOW
LOW
LOW
LOW
LOW
LOW
LOW
TS:
20
21
22
23
24
25
26
27
28
29
PRIORITY:
LOW
LOW
LOW
LOW
LOW
LOW
LOW
LOW
LOW
LOW
TS:
30
31
TYPE:
LOW
LOW
Note
This command would show correct information only when one of the lines is
down
