HCD-E1 Installation & Operation Manual Chapter 3 - Front Panel Operating Instructions
11/01/00 19:52 Configuration Parameters 3-13
Table 3-4 Control Port Parameters (Cont.)
Designation Function Values Configuration Guidelines
PARITY Selects the
method of parity
checking ODD Odd parity
EVEN Even parity
NONE Parity check disabled (available only with 8 data bits)
Default: NONE
Make sure that the parity is the same as on the
terminal.
INTERFACE Selects control
port interface DCE HCD-E1 operates as a DCE for the control terminal.
DTE HCD-E1 operates as a DTE, for connection via modem
to the control terminal.
Default: DCE
Select DCE when directly connected to the
control terminal.
Select DTE when connected to a modem.
Note: The INTERFACE parameter changes only the direction of the interface control (handshaking) signals, but not the functions of the
interface pins. Therefore, when connecting to a modem, it is necessary to use a cross cable.
AUX DEV (does
not appear
with HCD-E1
configured as
remote) Selects the
management
mode supported
by the HCD-E1
control port
TERMINAL Management by means of a supervision terminal.
NMS-SLIP Management by means of Telnet host or an
SNMP network management station.
NONE Not in use
Default: TERMINAL
