HCD-E1 Installation & Operation Manual Chapter 3 - Front Panel Operating Instructions
11/01/00 19:52 Operating Instructions 3-19
3.5 Operating Instructions
This section covers the following activities:
•
Turning HCD-E1 on
•
Checking the HCD-E1 configuration
•
Normal HCD-E1 operating indications
•
Monitoring the HCD-E1 performance
•
Turning HCD-E1 off
Refer to Section 3.6 for local configuration setup instructions.
Turning HCD-E1
On To turn HCD-E1 on, set the rear POWER switch to ON (AC version) or
connect it to the power supply (DC version). Upon turn-on, HCD-E1
performs a self-test: observe the front-panel indications.
During the self-test, HCD-E1 displays its current software revision:
After successfully completing the self-test procedure, HCD-E1 switches to
the default ALARM BUFFER screen.
If HCD-E1 fails the self-test, its LCD will display a description of the fault. In
this case, HCD-E1 must be repaired before it can be used again.
Warning
Access to the inside of the unit is permitted only to qualified and
authorized personnel
If the self-test reveals that configuration data selected by the user and stored
in the HCD-E1 database is corrupted, HCD-E1 generates the DB CHKSUM
ERR alarm message. In this case, it is necessary to initialize the database. To
do this, use the INIT DB command, if you have access to a control terminal.
Otherwise, do the following:
1. Set Section DB INIT of the internal switch S1 to ON.
2. Turn HCD-E1 on for a short time (until the power-up self-test is
performed) .
3. Return the DB INIT switch section to OFF. Now HCD-E1 is operating
with the default parameters. The parameter values included in the
default configuration are listed in Section 3-4.
4. Configure the unit, if necessary.
Refer to Chapter 2 for more detailed procedures.
HCD REV 2.1
SELF TEST
