HCD-E1 Installation & Operation Manual Chapter 5 - Troubleshooting and Diagnostics
01/01/01 08:15 Performance Diagnostics Data 5-19
Displaying the
Performance
Data on the
Front-Panel LCD To display the E1 and HDSL performance diagnostics data on the HCD-E1
front-panel LCD, use the following procedure:
Step Action Key Result
1 Bring the cursor to the left-hand field of
the top row (if it is not already there). CURSOR
2 Scroll to display PORT DIAG: SL in the top
row. SCROLL
3 Bring the cursor to the left-hand field in
the second row CURSOR The second row shows the first E1
performance item and its current value.
4 Scroll to see the other E1 performance
statistics SCROLL After each pressing of SCROLL, the second
row shows the current value of the next
item. Continue until the first item appears
again.
5 Bring the cursor to the left-hand field of
the top row (if not already there). CURSOR
6 Scroll to display HDSL DIAG in the top
row. SCROLL The right-hand field of the top row
indicates LINE1, meaning that the
displayed diagnostics data pertains to
line 1. Second row shows the first
performance item for line 1 and its current
value.
7 Bring the cursor to the left-hand field in
the second row. CURSOR
8 Scroll to see the other statistics. SCROLL After each SCROLL pressing, the second
row shows the current value of the next
item. Continue until the first item appears
again.
9 Bring the cursor to the right-hand field of
the top row (if it is not already there). CURSOR
10 Scroll to display LINE2. SCROLL Second row shows the first performance
item for line 2 and its current value.
11 Repeat steps 7 and 8 above to see the
other statistics of line 2. SCROLL After each pressing of SCROLL, the second
row shows the current value of the next
item. Continue until the first item appears
again.
