HCD-E1 Installation & Operation Manual Chapter 4 - Control from the Supervisory Port
11/01/00 19:23 HCD-E1 Command Set Description 4-47
Following is a list of fields appearing in the time slot display:
TS Indicates the main link time slot number 0 through 31
TYPE Indicates the type of time slot assignment:
NC
time slot not assigned
CH1 time slot is assigned to data channel 1
CH2 time slot is assigned to data channel 2
SL time slot is assigned to E1 sublink
DEDIC time slot is assigned for in-band management
After performing the command, HCD-E1 displays the date and the time
followed by the HCD-E1 prompt.
EXIT Purpose
End the current session and return control to the HCD-E1 front panel.
Syntax
EXIT
Use
•
Type:
EXIT
HCD-E1 performs the command and displays the date and the time
followed by the HCD-E1 prompt.
F Purpose
Define the codes used to be sent to the supervision terminal to perform the
following terminal control functions:
•
Clear the screen
•
Move the cursor to the screen home position.
•
Move the cursor to the right by one position.
The codes used by typical terminals are listed in the following table:
Function Terminal Type
TV920 VT52 VT100 Freedom100 Freedom220
Clear Screen 1B2A0000 N/A 1B5B324A 1B2A0000 1B5B324A
Cursor Home 1E000000 1B480000 1B5B4800 1E000000 1B5B4800
Cursor Right 0C000000 1B430000 1B5B3143 0C000000 1B5B0143
