HCD-E1 Installation & Operation Manual Appendix E - IR-IP Interface Module
View Menu E-23
Reset WAN
To reset the WAN interface:
•
From the Resets menu, type 3.
You will be prompted to confirm the reset operation.
Note
Resetting the WAN interface causes the WAN controller to be restarted. This
results in renegotiation of the WAN protocol parameters.
To continue your Telnet session, press any key within 15 seconds following
the confirmation of the reset operation.
E.11 View Menu
The View menu is used to view the IR-IP configuration data, and display
information on its ARP tables, multicast Groups tables and statistics.
To access the View menu:
•
From the Main menu, type 5.
The View menu appears (Figure E-19).
IR_IP S/W Ver. 1.00 31/IR (date)
Quick Setup
Management Access
Advanced Setup
Device Control
View
----------------------------------------------------------
1. Configuration and Connection
2. ARP Tables
3. Multicast Groups Table
4. Statistics
Press one of the numbers to select or ESC:
Figure E-19 View Menu
Configuration
and Connection This screen is used to view the configuration parameters of IR-IP. In
addition, you can also view the current status of the LAN and WAN
interface.
