Chapter 5 - Troubleshooting and Diagnostics HCD-E1 Installation & Operation Manual
5-32 Configuration Error Messages 01/01/01 08:15
Table 5-5 Configuration Error Messages (Cont.)
Error Code Terminal Message and Description
ERROR 05 MASTER AND FALLBACK CLOCK ARE THE SAME
You are trying to select the same source as both master and fallback clock source.
Check and change as required.
ERROR 06 ILLEGAL NUMBER OF TIME SLOTS SELECTED
The total number of high priority time slots selected exceeds the maximum (16 time
slots) allowed
ERROR 07* ILLEGAL NODE NUMBER
You are trying to select a node with number greater than 255.
ERROR 08 ILLEGAL SPEED FOR CURRENT AUXILIARY DEVICE
The AUTO (Autobaud) mode cannot be selected when the supervisory port is to
support the SLIP protocol (AUX DEV parameter is set to NMS-SLIP).
ERROR 09 DIFFERENT DEDICATED TS ALLOCATION
You are trying to select different time slots of main link and sublink for dedicated time
slot, and dedicated timeslot of sublink is not TS-0.
ERROR 10 CONFLICT IN SPEED PARAMETER
The number of time slots currently allocated to a data channel or sublink is not equal
to the number of time slots required to support the nominal data rate configured for
this channel/sublink under SPEED or NUM OF TS parameter. Check and change as
required.
ERROR 11 ILLEGAL TIME SLOT ALLOCATION
At least one main link time slot is being assigned to more than one user (for example to
the sublink and one of the channels). Check the dedicated time slot assignment, as
well as time slot assignment for each channel and for the E1 sublink, with particular
attention to automatic assignments (SEQ and ALT modes).
ERROR 12 TIME SLOT OUT OF RANGE
When using the SEQ or ALT mapping mode, the sum of the number of time slots
requested for a data channel (or sublink) and the starting time slot for that channel (or
sublink) exceeds 31. Check and change as required.
ERROR 13 CONFLICT BETWEEN CLOCK MODE AND FIFO SIZE
FIFO size can be other than AUTO only if the clock mode of the data channel is DTE2.
ERROR 14 ILLEGAL UNFRAMED CONFIGURATION
For working in unframed mode, all the 32 time slots must be assigned.
ERROR 15 INVALID MASTER CLOCK SOURCE
The channel you are trying to select as the fallback clock source is either not
connected, or its clock mode is not DTE2. Check and change as required.
ERROR 16 INVALID FALLBACK CLOCK SOURCE
The channel you are trying to select as the master clock source is either not connected,
or its clock mode is not DTE2. Check and change as required.
