Chapter 4 - Control from the Supervisory Port HCD-E1 Installation & Operation Manual
4-34 HCD-E1 Command Set Description 11/01/00 19:23
DSP HDSL PM Purpose
Display the contents of performance monitoring registers of a selected HDSL
line of the local HCD-E1. For an explanation of the HDSL performance
monitoring registers, refer to Section 5-3.
Syntax
DSP HDSL PM [LPX] [Option]
Use
1. To display the performance monitoring registers of the local unit, act as
follows:
•
To display the performance monitoring registers of HDSL line 1, type:
DSP HDSL PM LP1
or
DSP HDSL PM
•
To display the performance monitoring registers of HDSL line 2, type:
DSP HDSL PM LP2
•
To display current values of the performance monitoring registers of the
HDSL line 1, and then clear all these registers and restart the count
intervals, type:
DSP HDSL PM LP1/CA
or
DSP HDSL PM/CA
•
To display current values of the local performance monitoring registers of
the HDSL line 2, and then clear all these registers and restart the count
intervals, type:
DSP HDSL PM LP2/CA
A typical display is shown below:
PM HDSL LINE - 1
CURRENT ES = 0
CURRENT UAS = 0
CURRENT SES = 0
CURRENT BBE = 0
CURRENT TIMER = 388
For the description and allowed range of the parameters, see HDSL
Performance Monitoring in Section 5.3.
2. Press any key to see the next screen:
Note HCD-E1 displays this screen only if HCD-E1 has been working over
15 minutes after power-up.
