Chapter 3 - Front Panel Operating Instructions HCD-E1 Installation & Operation Manual
3-18 Configuration Parameters
Table 3-7 Download Parameters
Designation Function Values Configuration Guidelines
SL MODE Selects the in-band transmission
mode for the sublink NONE In-band SNMP and Telnet traffic is ignored
TS0/F In-band SNMP and Telnet traffic is received and
transmitted in time slot 0.
DEDIC In-band SNMP and Telnet traffic is received and
transmitted in a dedicated user-selected time slot.
Default: NONE
Select NONE also when using UNFRAMED
mode.
To use the S
a4
bit in time slot 0, select TS0/F
If you selected DEDIC, you must also select a
free time slot using the SL TS NUM
parameter.
ML MODE Selects the in-band transmission
mode for the selected main link. NONE In-band SNMP and Telnet traffic is ignored
DEDIC In-band SNMP and Telnet traffic is received and
transmitted in a dedicated user-selected time slot.
Default: NONE
Select NONE also when using UNFRAMED
mode.
If you selected DEDIC, you must also select a
free time slot using the ML TS NUM
parameter.
SL TS NUM Selects the free time slot when
SL MODE is selected as DEDIC. 1 to 31
Default: 31 If you have selected DEDIC both for SL and
ML modes, make sure that the assigned time
slot is the same for both links.
ML TS NUM Selects the free time slot when
ML MODE is selected as
DEDIC. 0 to 31
Default: 31 If you have selected DEDIC both for SL and
ML modes, make sure that the assigned time
slot is the same for both links.
Table 3-8 Priority Bumping Configuration Parameters
Designation Function Values
TS_1 to TS_31 Selects the time slot priority in the case one of
the HDSL lines is down. The time slots which
have been assigned high priority will continue
being sent on the remaining HDSL line.
LOW Low priority
HIGH High priority
Default: LOW
Note 1. The priority bumping will work in the framed mode only.
2. TS-0 has always HIGH priority. The maximum number of other time slots that can be configured to high priority is 16.
