Appendix E - IR-IP Interface Module HCD-E1 Installation & Operation Manual
E-14 Advanced Setup Menu
E.9 Advanced Setup Menu
The Advanced Setup menu is used to select the desired group of IR-IP
configuration parameters.
The parameters accessed through Advanced Setup menu supplement the
parameters available on the Quick Setup screen, by providing control over
all the other IR-IP parameters.
To access the Advanced Setup menu:
•
From the Main menu, press 3.
The Advanced Setup menu appears (Figure E-9).
IR_IP S/W Ver. 1.00 31/IR (date)
Quick Setup
Management Access
Advanced Setup
=====================================================================
1. Device identification
2. Interface Parameters
3. Protocol Parameters
4. Multicast IP
Press one of the numbers to select or ESC:
Figure E-9 Advanced Setup Menu
Device
Identification
Menu The Device Identification menu is used to define and store in the IR-IP
logistic information: the logical name of IR-IP, information on the contact
person and device location.
To access the Device Identification menu:
•
From the Advanced Setup menu, type 1.
The Device Identification menu appears (Figure E-10).
IR_IP S/W Ver. 1.00 31/IR (date)
Quick Setup
Management Access
Advanced Setup
.....................................................................
Device identification
=====================================================================
1. Device Name :IR-IP..
2. Contact Person :Name of contact Person
3. System Location :The location of this device
Press one of the numbers to select or ESC:
Figure E-10 Device Identification Menu
