9. Performance Commands
4200-A2-GB20-00
August 2002
9-11
Table 9-8.
REPT-OPSTAT-VCL Response Parameters
Parameter Explanation
tid Target
NE
identification
yy-mm-dd
Year, month, and day
hh:mm:ss
Hour, minute, and second
M
Message generated in response to an input command
c
If provided, ctag; otherwise 0
COMPLD Completed
DENY
Input command is denied
/* */
Enclosed are human readable comments – unspecified format
errcde Error
code
aid_vcl
As described for command parameters (see
REPT-OPSTAT-VCL Command Parameters
).
[op_vcl]
VCL operational parameters. Values are:
INCELLS: Rolling count of cells received on this VCL
OUTCELLS: Rolling count of cells transmitted on this VCL
LPBKINCELLS: A count of test cells received since the test started (up
to 2
32
-1)
LPBKOUTCELLS: A count of test cells received since the test started
(up to 2
32
-1)
LPBKRTDELAY: Average round trip delay in milliseconds since the test
has started. Only calculated on cells received; dropped cells are not
counted.
LPBKMNRTDELAY: Shortest round trip delay in milliseconds since the
test has started. Only calculated on cells received; dropped cells are not
counted.
LPBKMXRTDELAY: Longest round trip delay in milliseconds since the
test has started. Only calculated on cells received; dropped cells are not
counted.
LPBKTYPE: The type of OAM loopback test, if any, most recently
performed on the VCL:
– E2E: End-to-End OAM cell
– SEG: Segment OAM cell
– NOTST: No test has been performed on the VCL
LPBKSEGID: The ATM segment location identifier for the segment
loopback or blank.
value
Value of parameter specified by op_vcl
