JTAG Boundary Scan Register (BSR)
DSP56366 24-Bit Digital Signal Processor User Manual, Rev. 4
4-16 Freescale Semiconductor
43 A7 Output3 Data 119 HSCKR — Control
44 A6 Output3 Data 120 HSCKR Input/Output Data
45 A[8:0] — Control 121 HSCKT — Control
46 A5 Output3 Data 122 HSCKT Input/Output Data
47 A4 Output3 Data 123 SCKR — Control
48 A3 Output3 Data 124 SCKR Input/Output Data
49 A2 Output3 Data 125 SCKT — Control
50 A1 Output3 Data 126 SCKT Input/Output Data
51 A0 Output3 Data 127 FSR — Control
52 BG Input Data 128 FSR Input/Output Data
53 AA0 — Control 129 FST — Control
54 AA0 Output3 Data 130 FST Input/Output Data
55 AA1 — Control 131 SDO5/SDI0 — Control
56 AA1 Output3 Data 132 SDO5/SDI0 Input/Output Data
57 RD Output3 Data 133 SDO4/SDI1 — Control
58 WR Output3 Data 134 SDO4/SDI1 Input/Output Data
59 BB — Control 135 SDO3/SDI2 — Control
60 BB Input/Output Data 136 SDO3/SDI2 Input/Output Data
61 BR Output2 Data 137 SDO2/SDI3 — Control
62 TA Input Data 138 SDO2/SDI3 Input/Output Data
63 PINIT Input Data 139 SDO1 — Control
64 SCKR_1 Control 140 SDO1 Input/Output Data
65 SCKR_1 Input/Output Data 141 SDO0 — Control
66 FSR_1 Control 142 SDO0 Input/Output Data
67 FSR_1 Input/Output Data 143 HREQ — Control
68 RD,WR — Control 144 HREQ Input/Output Data
Table 4-10 DSP56366 BSR Bit Definition (continued)
Bit
#
Pin Name Pin Type
BSR Cell
Type
Bit
#
Pin Name Pin Type
BSR Cell
Type
