JTAG Boundary Scan Register (BSR)
DSP56366 24-Bit Digital Signal Processor User Manual, Rev. 4
4-14
Freescale Semiconductor
4.9
JTAG Boundary Scan Register (BSR)
The boundary scan register (BSR) in the DSP56366 JTAG implementation contains bits for all device
signal and clock pins and associated control signals. All bidirectional pins have a single register bit in the
boundary scan register for pin data, and are controlled by an associated control bit in the boundary scan
register. The boundary scan register bit definitions are described in
Table 4-9 JTAG Identification Register Configuration
31
28
27
22
21
12
11
1
0
Version
Information
Customer Part
Number
Sequence
Number
Manufacturer
Identity
1
0000
000111
0001001111
00000001110
1
Table 4-10 DSP56366 BSR Bit Definition
Bit
#
Pin Name
Pin Type
BSR Cell
Type
Bit
#
Pin Name
Pin Type
BSR Cell
Type
0
SDO4_1/SDI1_1
—
Control
76
FST_1
—
Control
1
SDO4_1/SDI1_1
Input/Output
Data
77
FST_1
Input/Output
Data
2
IRQA
Input
Data
78
SDO5_1/SDI0_1
Control
3
IRQB
Input
Data
79
SDO5_1/SDI0_1
Input/Output
Data
4
IRQC
Input
Data
80
RES
Input
Data
5
IRQD
Input
Data
81
HAD0
—
Control
6
D23
Input/Output
Data
82
HAD0
Input/Output
Data
7
D22
Input/Output
Data
83
HAD1
—
Control
8
D21
Input/Output
Data
84
HAD1
Input/Output
Data
9
D20
Input/Output
Data
85
HAD2
—
Control
10
D19
Input/Output
Data
86
HAD2
Input/Output
Data
11
D18
Input/Output
Data
87
HAD3
—
Control
12
D17
Input/Output
Data
88
HAD3
Input/Output
Data
13
D16
Input/Output
Data
89
HAD4
—
Control
14
D15
Input/Output
Data
90
HAD4
Input/Output
Data
15
D[23:13]
—
Control
91
HAD5
—
Control
16
D14
Input/Output
Data
92
HAD5
Input/Output
Data
