ESAI_1 Programming Model
DSP56366 24-Bit Digital Signal Processor User Manual, Rev. 4
9-10
Freescale Semiconductor
9.3.5
ESAI_1 Receive Control Register (RCR_1)
The read/write Receive Control Register (RCR_1) controls the ESAI_1 receiver section.
Hardware and software reset clear all the bits in the RCR_1 register.
9.3.6
ESAI_1 Common Control Register (SAICR_1)
The read/write Common Control Register (SAICR_1) contains control bits for functions that use both the
receive and transmit sections of the ESAI_1.
Hardware and software reset clear all the bits in the SAICR_1 register.
9.3.7
ESAI_1 Status Register (SAISR_1)
The Status Register (SAISR_1) is a read-only status register used by the DSP to read the status and serial
input flags of the ESAI_1.
11
10
9
8
7
6
5
4
3
2
1
0
Y:$FFFF97
RSWS1 RSWS0 RMOD
RMOD
RWA
RSHFD
RE3
RE2
RE1
RE0
23
22
21
20
19
18
17
16
15
14
13
12
RLIE
RIE
REDIE
REIE
RPR
RFSR
RFSL
RSWS4 RSWS3 RSWS2
Reserved bit - read as zero; should be written with zero for future compatibility.
Figure 9-8 RCR_1 Register
11
10
9
8
7
6
5
4
3
2
1
0
Y:$FFFF94
ALC
TEBE
SYN
OF2
OF1
OF0
23
22
21
20
19
18
17
16
15
14
13
12
Reserved bit - read as zero; should be written with zero for future compatibility.
Figure 9-9 SAICR_1 Register
