JTAG Boundary Scan Register (BSR)
DSP56366 24-Bit Digital Signal Processor User Manual, Rev. 4
Freescale Semiconductor 4-15
17 D13 Input/Output Data 93 HAD6 — Control
18 D12 Input/Output Data 94 HAD6 Input/Output Data
19 D11 Input/Output Data 95 HAD7 — Control
20 D10 Input/Output Data 96 HAD7 Input/Output Data
21 D9 Input/Output Data 97 HAS/A0 — Control
22 D8 Input/Output Data 98 HAS/A0 Input/Output Data
23 D7 Input/Output Data 99 HA8/A1 — Control
24 D6 Input/Output Data 100 HA8/A1 Input/Output Data
25 D5 Input/Output Data 101 HA9/A2 — Control
26 D4 Input/Output Data 102 HA9/A2 Input/Output Data
27 D3 Input/Output Data 103 HCS/A10 — Control
28 D[12:0] — Control 104 HCS/A10 Input/Output Data
29 D2 Input/Output Data 105 TIO0 — Control
30 D1 Input/Output Data 106 TIO0 Input/Output Data
31 D0 Input/Output Data 107 ACI — Control
32 A17 Output3 Data 108 ACI Input/Output Data
33 A16 Output3 Data 109 ADO — Control
34 A15 Output3 Data 110 ADO Input/Output Data
35 A[17:9] — Control 111 HREQ/HTRQ — Control
36 A14 Output3 Data 112 HREQ/HTRQ Input/Output Data
37 A13 Output3 Data 113 HACK/RRQ — Control
38 A12 Output3 Data 114 HACK/RRQ Input/Output Data
39 A11 Output3 Data 115 HRW/RD — Control
40 A10 Output3 Data 116 HRW/RD Input/Output Data
41 A9 Output3 Data 117 HDS/WR — Control
42 A8 Output3 Data 118 HDS/WR Input/Output Data
Table 4-10 DSP56366 BSR Bit Definition (continued)
Bit
#
Pin Name Pin Type
BSR Cell
Type
Bit
#
Pin Name Pin Type
BSR Cell
Type
