Pearl Mini User Guide
Vesa mounting the device
l
Disable the video output port (if unused).
l
Remove unused channels or layouts.
l
Reduce the number of channels created.
l
Ensure video sources come in at the right resolution so that Pearl Mini doesn't have to up scale or down
scale the video source.
Vesa mounting the device
The rear panel of Pearl Mini has vesa mounting holes to fit a standard, 75mm × 75mm vesa mount. Use four
M4 screws with a maximum length of 5mm to mount the plate to the rear panel of Pearl Mini.
Do not insert screws longer than the recommended 5mm. Using longer screws can damage the
device.
34
