8-32
TNC 360 3 Standard Data Transmission Protocol 8/95
Peripheral unit Transmission path
1st line of file
TNC
.
.
.
Last line of file
.
.
.
In this transfer method, the TNC can stop transmission with and continue it with .
If the file name in the first line of the file and the name indicated in the TNC are not identical, the
TNC reads each block in and searches for the file name concerned.
If the END PGM-block has been read in, and the selected name is not known, the TNC remains
static without an error message, and transfer must be terminated with the END key.
Example: Reading in program 100.H.
Peripheral unit
1st line PGM100
Last line PGM 100
Transmission path TNC
.
.
.
.
.
.
100.H "START"
If, in this case, the last PGM-block ends without the character, transfer is terminated
without an error message but the data is not stored. This means that a program on the data
medium with incorrect program name will be overlooked.
