HEIDENHAIN TNC 335 Technical Manual User Manual
Page 130
8/95
TNC 360
1 Machine Axes
4-33
Set
Reset
M2704
Activate PLC positioning X axis
PLC
NC; PLC
M2705
Activate PLC positioning Y axis
M2706
Activate PLC positioning Z axis
M2707
Activate PLC positioning 4th axis
– The positions which are given are referenced to the machine datum (MP960.x).
– Software limit switches are not considered.
– Tool corrections are not calculated.
– The path compensation must be terminated before a PLC positioning.
– PLC positioning is not displayed in the test graphics.
