SDM-300L3 Satellite Modem Revision 1
Remote Control Operation MN/SDM300L3.IOM
A–36
Bulk Consol.
Status
(continued)
Parameter
Number Parameter Name
(Command Reference)
Description
(Note 1)
(Note 2)
(Note 1)
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
Transmit data fault
(ref. 'TDF_' command).
Receive data fault
(ref. 'RDF_' command).
Interface service channel TX1
(ref. 'ISCL_' command).
Interface service channel TX2
(ref. 'ISCL_' command).
Interface service channel RX1
(ref. 'ISCL_' command).
Interface service channel RX2
(ref. 'ISCL_' command).
System modem type
(ref. 'SMT_' command).
Modem operation mode
(ref. 'MOM_' command).
MODEM REMOTE/LOCAL mode.
Transmit data phase
(ref. 'TDP_' command).
Receive data phase
(ref. 'RDP_' command).
Drop Data Format
(ref. 'DDF_' command).
Insert Data Format
(ref. 'IDF_' command).
Bulk Drop Channels Assignment.
Bulk Insert Channels Assignment.
Insert E1 CRC Enable
(ref. 'ICRC_' command).
Modem Reference Clock
(ref. 'MRC_' command).
Modulator Spectrum Rotation
(ref. 'MSR_' command).
p53 = n, where 'n' is '0' (NONE), '1' (DATA), or '2' (AIS).
p54 = n, where 'n' is '0' (NONE), '1' (DATA), or '2' (AIS).
p55 = nnn, service channel level in dBm.
p56 = nnn, service channel level in dBm.
p57 = nnn, service channel level in dBm.
p58 = nnn, service channel level in dBm.
p59 = n, where 'n' is '0' (IDR), '1' (IBS), ''2' (EFD), 3'
(CUSTOM), '4' (DI), '5' (ASYNC), or ‘8’ (AUPC)
p60 = n, where 'n' is '1' (TX_ONLY), '2' (RX_ONLY), '3'
(DUPLEX).
p61 = n, where 'n' is '0' (LOCAL), '1' (REMOTE).
p62 = n, where 'n' is '0' (NRM), '1' (INV).
p63 = n, where 'n' is '0' (NRM), '1' (INV).
p64 = n, where 'n' is '0' (T1), '1' (T1ESF), '2' (E1CCS), '3'
(E1CAS), '6' (E131TS), '7' (T1S), and '8' (T1ESFS).
p65 = n, where 'n' is '0' (T1), '1' (T1ESF), '2' (E1CCS), '3'
(E1CAS), '6' (E131TS), '7' (T1S), and '8' (T1ESFS).
p66 = dd;cc_dd;cc_dd;cc_dd;cc......, as defined by the
BDCA_ command.
p67 = ii;cc_ii;cc_ii;cc_ii;cc......, as defined by the BICA_
command.
p68 = n, where 'n' is '0' (off) or '1' (on).
p69 = n, where 'n' is '0' (INT), '1' (EXT1), '2' (EXT5), '3'
(EXT10), or '4' (EXT20), respectively.
p70 = n, where 'n' is '0' (NRM), '1' (INV).
