background image

SDM-300L3 Satellite Modem

Revision 1

Front Panel Operation

MN/SDM300L3.IOM

4–64

FUNCTION

SELECT:

MONITOR: LNB CURRENT

LNB CURRENT

XXX mA


Monitors the LNB current or “LNB POWER OFF.”
Current displayed is 0 to 500 mA in 1 mA increments.

FUNCTION

SELECT:

MONITOR: LNB VOLTAGE

LNB VOLTAGE

XX VOLTS


Monitors the LNB voltage or “LNB VOLTAGE OFF.”
Voltage displayed is 0 to 24 VDC, in 1volt increments.

FUNCTION

SELECT:

MONITOR: ODU CURRENT

ODU CURRENT

XXXX mA


Monitors the ODU current or “ODU POWER OFF.”
Current displayed is 0 to 5000 mA in 1 mA increments.
