SDM-300L3 Satellite Modem

Revision 1

Front Panel Operation

MN/SDM300L3.IOM

4–59

FUNCTION SELECT: CONFIGURATION: FLEX MUX:

RX CHAN #4 DATA RATE

RX CHAN #4 DR

9.6 Kbps

RECEIVE CHANNEL 4 DATA RATE: 0.6 to 64.0 kbps

Note: DR is not displayed if AUPC or DISABLED were selected for MODE.

FUNCTION SELECT: CONFIGURATION: FLEX MUX:

RX CHAN #4 PHASE

RX CHAN #4 PHASE
CLK:NRM DATA:NRM

RECEIVE CHANNEL 4 PHASE:

NRM or INV (for both clock and data phase)

Note: PHASE is not displayed if AUPC or DISABLED were selected for MODE.
