SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–81
FUNCTION SELECT: REMOTE AUPC: CONFIGURATION:
TX 2047 PATTERN (CONDITIONAL)
TX 2047 PATTERN
OFF
IMPORTANT
Conditional: This menu is available when either the ASYNC or AUPC
selection is made from the Modem Type menu, located under the
Utility: Modem Type menu.
Requires either the Overhead Card installed with the ASYNC/AUPC
option or the Reed-Solomon Card with AUPC option.
Programs the remote TX 2047 pattern On or Off at the far end of the link. Modems at
both ends of the link shall be locked.
Note: This program is for control or last known status.
FUNCTION SELECT: REMOTE AUPC: CONFIGURATION:
REMOTE AUPC: MONITOR (CONDITIONAL)
REMOTE AUPC
MONITOR
IMPORTANT
Conditional: This menu is available when either the ASYNC or AUPC
selection is made from the Modem Type menu, located under the
Utility: Modem Type menu.
Requires either the Overhead Card installed with the ASYNC/AUPC
option or the Reed-Solomon Card with AUPC option.
