SDM-300L3 Satellite Modem Revision 1
Front Panel Operation MN/SDM300L3.IOM
4–111
4.6.6.6 FUNCTION SELECT: UTILITY:SYSTEM
UTILITY
SYSTEM
Select information to view using the [
← ] [ → ] arrow keys, then press .
FUNCTION SELECT: UTILITY: SYSTEM:TIME/DATE
TIME: 12:00:00AM
DATE: 7/04/1976
Time of day and date display/set function.
The current time and date in the modem’s memory are displayed when selected. To
change the modem time and/or date, press . Press [
← ] or [ → ] to position the
cursor over the parameter to be changed. Press [ ↑ ] or [ ↓ ] to change the parameter. Once
the parameters are displayed as desired, press to set the time and date.
FUNCTION SELECT: UTILITY: SYSTEM: REMOTE BAUD RATE
REMOTE BAUD RATE
9600 bps
EVEN
The parity and baud rate settings of the modem are displayed.
To change the modem baud rate and/or parity, press . Press [
← ] or [ → ] to
position the cursor over the parameter to be changed. Press [ ↑ ] or [ ↓ ] to change the
parameter. Once the parameters are displayed as desired, press to set the baud
rate and parity. The parity can be set to EVEN, ODD, or NONE. The baud rate can be set
from 150 to 19200 bps.
