SDM-300L3 Satellite Modem Revision 0
Specifications MN/SDM300L3.IOM
14–39
14.16.1 IDR Primary Data Interfaces
When configured for IDR operation, the board performs these functions:
• Receives and performs clock and data recovery on incoming G.703 T1 and E1
pseudo-ternary data.
• Clock dejitter is performed per G.823 and G.824, and any data decoding (AMI,
B8Z5, or HDB3) required per G.703 is also done.
14.16.2 IDR Framing
Multiplexes in compliance with the standard IESS-308 96 kbps ESC overhead onto the
data and provides both the data and rate exchanged clock to the modulator portion of the
base modem.
• Performs the corresponding demultiplexing of RX satellite data received from the
demodulator portion of the modem.
• Resulting G.703 data is optionally encoded (AMI, B8Z5, or HDB3) before being
output on the 50-pin connector.
14.16.3 IDR Engineering Service Channel
Bi-directional processing of the components of the ESC channel, including the ADPCM
audio channels, 8 kbps data channel, and fault indications specified by IESS-403 and
IESS-308.
Option of using the ADPCM portion of the satellite overhead for a single 64 kbps ESC
data channel in addition to (and with the same format as) the 8 kbps data channel.
14.16.4 Optional: Dual 32 Kpps ADPCM (2XASPCM Audio)
With this option, the two 32 kpps ADPCM voice Codecs provide a 64 kpps data stream in
place of normal 64 kbps terrestrial data. This operating mode uses IBS 1/15 overhead
framing.
