FUNCTION SELECT: UTILITY: INTERFACE: BUFFER PROGRAM
BUFFER PROGRAM
BITS
Allows selection of either Bits or Milliseconds for the receive buffer.
• For the modem to calculate buffer size, select Milliseconds.
• For a specific buffer depth, select Bits.
IMPORTANT
This menu indicates whether the Bits or Milliseconds menu is
displayed under Configuration: Interface Buffer Size.
FUNCTION SELECT:UTILITY:INTERFACE:
FRAMING STRUCTURE
FRAMING
STRUCTURE
Displays the currently selected framing type and structure of the data. This function is
used with the buffer program in ms for plesiochronous buffer slips.
Upon entry, the framing type (T1 or E1) is displayed on Line 1. The framing structure of
each type (None or G.704) is displayed on Line 2. Press [
← ] or [ → ] and [ ↑ ] or [ ↓ ] to
select framing structure and type. Press [ENTER] to execute the change .
