SDM-300L3 Satellite Modem Revision 1
Remote Control Operation MN/SDM300L3.IOM
A–9
RX 8PSK 2/3
IESS-310
Operation Command:
Response:
Status:
Response: >add/R310_xxx'cr''lf']
>add/R310_xxx'cr''lf'] Where: xxx = ON or OFF.
RX IESS-315
Operation Command:
Response:
Status:
Response: >add/R315_xxx'cr''lf']
>add/R315_xxx'cr''lf'] Where: xxx = ON or OFF.
LNB Power Command:
Response:
Status:
Response: >add/LNB_xxx'cr''lf']
>add/LNB_xxx'cr''lf'] Where: xxx = ON or OFF.
LNB Voltage Command:
Response:
Status:
Response: >add/LNBV_xxx'cr''lf']
>add/LNBV_xxx'cr''lf'] Where: xxx = 13,18, or 24 Volts
LNB
Reference
Enable Command:
Response:
Status:
Response: >add/LNBR_xxx'cr''lf']
>add/LNBR_xxx'cr''lf'] Where: xxx = ON or OFF.
LNB Power
Monitor Low
Current
Threshold Command:
Response:
Status:
Response: >add/LNBL_xxx'cr''lf']
>add/LNBL_xxx'cr''lf'] Where: xxx = 0 to 500 in 1 mA steps
LNB Power
Monitor High
Current
Threshold Command:
Response:
Status:
Response: >add/LNBH_xxx’cr’’lf’]
>add/LNBH_xxx’cr’’lf’]
Where: xxx = 0 to 500 in 1 mA steps
A.3.3 Interface Configuration Commands
Interface
Transmit
Overhead
Type Command:
Response:
Status:
Response: >add/ITOT_xxxxx'cr''lf']
>add/ITOT_xxxxx'cr''lf'] Where: xxxxx = NONE, IDR, IBS, DI, ASYNC,
AUPC, or FLEX.
Interface
Receive
Overhead
Type Command:
Response:
Status:
Response: >add/IROT_xxxxx'cr''lf']
>add/IROT_xxxxx'cr''lf'] Where: xxxxx = NONE, IDR, IBS, DI, ASYNC,
AUPC, or FLEX.
TX Driver
Type Command:
Response:
Status:
Response: >add/TXDR_xxxxx'cr''lf']
>add/TXDR_xxxxx'cr''lf'] Where: xxxxx = G703, V35, RS422, or RS232.
RX Driver
Type Command:
Response:
Status:
Response: >add/RXDR_xxxxx'cr''lf']
>add/RXDR_xxxxx'cr''lf'] Where: xxxxx = G703, V35, RS422, or RS232.
Transmit
Clock Command:
Response:
Status:
Response: >add/TC_xxx'cr''lf']
>add/TC_xxx'cr''lf'] Where: xxx = INT (internal SCT clock), EXT
(external TX terrestrial clock), REF (external
clock-reference frequency).
External
Clock-
Reference
Frequency
Command:
Response:
Status:
Response: >add/ERF_nnnnn.n'cr''lf']
>add/ERF_nnnnn.n'cr''lf'] Where: nnnnn.n = 8.0 to 10000.0 (external clock
frequency in kHz).
Transmit
Clock
Phase Command:
Response:
Status:
Response: >add/TCP_xxxx'cr''lf']
>add/TCP_xxxx'cr''lf'] Where: xxxx = NRM (normal clock phasing), INV
(inverted clock phasing), AUTO (automatic clock
phasing).
