Table 4-2. SDM-300L Custom Modem Defaults (Continued)
Utility Interface
TX Overhead Type None E1 Insert CRC On
RX Overhead Type None Backward Alarm RX #X On
TX Terr Interface RS422 ASYNC TX Type RS232
RX Terr Interface RS422 ASYNC RX Type RS232
Buffer Program Bits IDR TX ESC Type 2-32k Audio
Framing Structure T1 Framing Structure: G.704
E1 Framing Structure: G.704 IDR RX ESC Type 2-32k Audio
RTS TX-IF CNTRL Off IBS TX ESC Type Off
TX Data Phase Normal IBS RX ESC Type Off
RX Data Phase Normal CTS Delay 0 seconds
Utility Outdoor Unit
ODU FSK Address 1 ODU PWR Leveling Off
ODU Output Power Off
Utility System
Time 12:00:00 AM Self Test Off
Date 7/04/76 Display Contrast 64
Remote Baud Rate 9600 bit/s M&C Firmware FW/NNNNNN-DDR
MM/DD/YYYY
Remote Address 1 Boot Firmware FW/NNNNNN-DDR
MM/DD/YYYY
Version:
Remote Type RS485 (2-Wire) FPGA Firmware FW/NNNNNNR
MM/DD/YYYY
Turbo Firmware FW/NNNNR
Operational Mode Duplex Demo Mode Off
Year Display 2-Digit EXT AGC: Min Pwr 0 volts
EXT AGC: Max Pwr 10 volts
Utility Modem Type
Modem Type Custom Card #1 Overhead 01
Rev Emulation Current Card #2 Reed-Solomon 02
Intelsat Data 50 Pin Card #3 Reed-Solomon 03
NRZ Data I/O RS-422 Local Modem AUPC Off
